- Assembled dimensions
- 75 in W x 43 in D x 81 in H maximum (191 x 110 x 206 cm)
- Total weight
- 715 lb (325 kg)
- Largest single piece
- 76 in W x 29 in D x 36 in H
- User limits
- Maximum user weight 400 lb (181 kg); user height 4 ft 8 in to 6 ft 8 in
- Electrical
- 120 V AC, 60 Hz, single phase; dedicated 20 A circuit; NEMA 5-20P plug
- Power consumption
- Peak approximately 1,500 W / 13 A at 120 V; sleep/standby less than 100 W
- Connectivity
- Hardwired Cat5 or Cat6 Ethernet; no Wi-Fi
- Installation clearance
- 3 ft clearance on all sides
- Room/site envelope
- Manual calls for a room larger than 8 ft x 8 ft with an 8 ft ceiling; 12 ft x 12 ft is recommended; flat hard subfloor, privacy, ventilation, route access, and a commercial emergency override are described
- Red/NIR PBM output figures
- 660 nm red and 850 nm near-infrared; manual FAQ states 100 mW/cm2 without publishing measurement plane, tolerance, or uniformity
- PEMF/PEF frequency
- 0.5 Hz to 50 MHz published; manual does not publish an SI field-strength value, waveform, pulse width, amplitude, or duty cycle
- Molecular hydrogen flow
- 600 mL/min manufacturer FAQ claim through a disposable nasal cannula; concentration, purity, pressure, temperature, and output-test method are not published
- Water and ventilation
- Distilled water only; manual says a small amount of ozone is emitted and requires ventilation; no rate or concentration is published
