- Energy profile
- The manufacturer describes four energies in one platform: photo bio-modulation, electrodynamic voltage, frequencies and harmonics, and pulsed electromagnetic fields (PEMF).
- Dimensions and mass
- 28 in H x 18.5 in W x 24 in D; approximately 68 lb.
- Pulsed modulation
- 217 kHz carrier with frequencies ranging from 5 Hz to 50 kHz; manufacturer spec sheet says variable magnetic fields pulse up to 50 kHz while sweeping ranges on command through recipes.
- Broader spectrum claim
- The 2023 manufacturer spec sheet lists a frequency spectrum of 7 Hz to 1 GHz and beyond to visible light. This is a broad multi-energy platform claim and is not a PEMF-only operating range.
- Electrical
- 120 VAC 60 Hz or 240 VAC 50 Hz input; a standard grounded 110 V / 15 A outlet is required; up to 1100 W at peak power. The manual requires a verified earth ground and says to use the supplied grounded power cord or specified UL/NRTL-listed cord.
- Photonic hardware
- 12 plasma tubes, two each of six gases: argon, helium, krypton, iodine, neon, and xenon. The manufacturer spec sheet says the tubes produce more than 1000 wavelengths in infrared, far infrared, and visible spectra.
- Control and connectivity
- Built-in 4-inch TFT LCD; remote smartphone/tablet/laptop operation; Ethernet and supplied USB Wi-Fi adapter; myCloud recipe management and updates.
- Safety hardware
- Emergency stop button, internal tip-over switch, fault indicator, cooling fans/vents, and IP20 degree of protection are documented in the manual.
