Harvia · Commercial steam generators
Harvia HGX90 Steam Generator
A professional wall-mounted electric steam generator with separate touch control options for steam-room fragrance, lighting and fan control.
Steam RoomSteam Bath
Reference the modality footprint before choosing a unit
Plan the room with a standard steam room footprint, then confirm exact dimensions on the maker's spec sheet.
Explore this generic equipment footprint, then place it in your studio plan.
Generic reference model
Steam room
7.2′ × 7.2′ floor envelope
Generic planning geometry for early space planning. It is not a manufacturer-specific product, installation drawing, or purchasing specification; confirm the selected model's final envelope, service clearances, utilities, and ceiling requirements before ordering.
Place reference in planner
Key features
- Wall-mounted vertical installation
- Xafir touch-control compatibility
- Remote-use option
- Water impurity sediment cup
- Linkable extra power units
Specifications
- Power output
- 9 kW
- Steam output capacity
- 12 kg/h
- Recommended room volume
- 106–600 ft³
- Dimensions
- 9.06 H × 5.91 W × 20.87 D in
- Net weight
- 21.4 lb
- Electrical
- 400 V 3N~, 50/60 Hz, 3 × 16 A
- Protection class
- IPX2
- Certification
- CE
