HPO TECH · Multiplace Hyperbaric Chamber
HPO TECH Mediterranean
A four-seat multiplace chamber: everyone inside shares one pressure profile and one session clock, breathing oxygen through individual BIBS demand-valve masks rather than an ambient fill. Built to 2.0, 2.4 or 3.0 ATA, with one oxygen concentrator per occupied seat.
Hyperbaric oxygen
Space planning
Reference the modality footprint before choosing a unit
This product page does not have an exact 3D model yet. The planning references below are generic envelopes tied to the listed modality, not this manufacturer's product.
Explore this generic equipment footprint, then place it in your studio plan.
Generic reference model
Hyperbaric chamber
7.9′ × 3.2′ floor envelope
Generic planning geometry for early space planning. It is not a manufacturer-specific product, installation drawing, or purchasing specification; confirm the selected model's final envelope, service clearances, utilities, and ceiling requirements before ordering.
Place reference in planner
Key features
- Two transparent acrylic windows for open visibility during sessions
- 3 ergonomic chair models, including a luxury electric Maybach chair range
- Adjustable LED RGB ambient lighting
- Built-in entertainment system (large-screen TV or tablets)
- UV-C light disinfection with automatic occupancy-sensor disable
- USB 3.0 port for software updates, custom settings, and session-archive download
- Mechanical dial pressure indicator for analog cross-check
- Safe gas overboard dump system
- Smart environmental climate control — spark-free brushless fan motors + water-type chiller radiators, 18-25°C therapeutic range
Specifications
- Max operating pressure
- 3.0 ATA (2.0 bar)
- Design pressure
- 3.2 ATA (2.2 bar)
- Test pressure
- 4.1 ATA (3.1 bar)
- Build pressure options
- 2.0 ATA / 2.4 ATA / 3.0 ATA
- Capacity
- 1 to 4 seats, modular
- Windows
- Two transparent acrylic, configurable arrangement
- Oxygen delivery
- BIBS demand-valve regulator with anti-allergic silicone mask; minimum flow 75 L/min
- Oxygen concentrators
- One per occupant — 4 units on a 4-seat build (optional equipment)
- Air compressor
- 1 unit (optional equipment)
- Air cooler
- 1 unit, included in the system
- Control system
- Industrial PLC automation with mirrored external and internal touchscreen tablets
- Internal climate range
- 18-25°C therapeutic target
- Disinfection
- UV-C, automatically disabled by an occupancy sensor
- Data interface
- USB 3.0 port; every session protocol written to an on-board data logger
- Patient monitoring
- Chamber penetrations for EEG, ECG, TCOM and blood pressure
Product-row differences
Direct product-row facts compared with HPO TECH Atlantis; shared values are omitted.
Product row lists in the box: Hyperbaric chamber, 1-4 seats, Air cooler, 1 unit, BIBS built-in breathing system with anti-allergic silicone mask and demand-valve regulator, Air compressor, 1 unit — listed by HPO TECH as optional equipment, quoted separately and Oxygen concentrators, one per seat — listed by HPO TECH as optional equipment, quoted separately.
Product details
- Regulatory status & certifications
- CE (MDD/MDR)UKCAASME PVHOASME U-StampPEDISO 13485ISO 9001ISO 45001ISO 14001ISO 27001NFPAThai FDAGhana FDASaudi FDA (SFDA)UAE MOHAP/EDERegistration or listing does not by itself mean a device is FDA approved or cleared. Confirm model-specific status and intended use with the manufacturer and the relevant regulator before purchase.
What's included
- Hyperbaric chamber, 1-4 seats
- Air cooler, 1 unit
- BIBS built-in breathing system with anti-allergic silicone mask and demand-valve regulator
- Air compressor, 1 unit — listed by HPO TECH as optional equipment, quoted separately
- Oxygen concentrators, one per seat — listed by HPO TECH as optional equipment, quoted separately
