REDDOT LED · Red light therapy panels (OEM/wholesale)
RDPRO300-FS
REDDOT's smallest professional panel, and an OEM product rather than a retail one — the minimum order is twenty units, so a delivered panel may wear someone else's badge. Sixty LEDs over a 30 by 20 cm patch at more than 182 mW/cm² at 15 cm: a localised tool, not a full-body one.
3-year coverage for manufacturing defects
Warranty
Red light therapy
Space planning
Reference the modality footprint before choosing a unit
This product page does not have an exact 3D model yet. The planning references below are generic envelopes tied to the listed modality, not this manufacturer's product.
Explore this generic equipment footprint, then place it in your studio plan.
Generic reference model
Infrared panel
4.0′ × 2.0′ floor envelope
Generic planning geometry for early space planning. It is not a manufacturer-specific product, installation drawing, or purchasing specification; confirm the selected model's final envelope, service clearances, utilities, and ceiling requirements before ordering.
Place reference in planner
Generic reference model
Red light bed
7.1′ × 3.6′ floor envelope
Generic planning geometry for early space planning. It is not a manufacturer-specific product, installation drawing, or purchasing specification; confirm the selected model's final envelope, service clearances, utilities, and ceiling requirements before ordering.
Place reference in planner
Key features
- Sixty LEDs across a 30 x 20 cm coverage area — sized for a joint, a neck or a patch of skin rather than a whole body
- Over 182 mW/cm² measured at 15 cm from a 103 W panel
- Three wavelength arrays chosen at order: 660/850 nm, a five-wavelength array, or a seven-wavelength array including 480 nm and 1060 nm
- Adjustable session timer, operable from the panel, the bundled remote or REDDOT's app
- 3.8 kg in an SPCC steel shell with a carrying handle, rated to work between -10°C and 45°C
- Sold OEM and ODM with a minimum order of twenty units, so delivered panels may carry a third-party brand
Specifications
- Model number
- RDPRO300-FS
- Wavelengths (build option 1)
- 660 nm : 850 nm, single-chip — the build this record documents
- Wavelengths (build option 2)
- 630 : 660 : 810 : 830 : 850 nm, single-chip
- Wavelengths (build option 3)
- 480 : 630 : 660 : 810 : 830 : 850 : 1060 nm, single-chip
- LED count
- 60 pcs (Taiwan Epistar / UltraChip)
- Irradiance
- >182 mW/cm² at 15 cm
- Max coverage area
- 30 cm x 20 cm
- Power output
- 103 W
- Dimensions
- 26.9 x 23 x 6.6 cm
- Weight
- 3.8 kg
- Shell material
- SPCC steel
- LED lifespan
- 50,000 hours
- Working environment
- -10°C to 45°C
- Controls
- On-panel interface, bundled remote, and app control for remote operation
- Minimum order quantity
- 20 units; sample and small-batch orders available, OEM and ODM offered
Product-row differences
Direct product-row facts compared with REDDOT LED RDPRO1500-FS; shared values are omitted.
Warranty: this product lists 3-year coverage for manufacturing defects; REDDOT LED RDPRO1500-FS lists 3 years.
Product row lists in the box: Handle.
Product details
- Regulatory status & certifications
- FDA registrationFCCCEROHSRegistration or listing does not by itself mean a device is FDA approved or cleared. Confirm model-specific status and intended use with the manufacturer and the relevant regulator before purchase.
What's included
- LED Therapy Light
- Eye Protection
- Handle
- Remote control
- Power Cable
- Patch Cable
