Vacuactivus Antarctica Barrel
A fully electric whole-body chamber that makes its own cold, so there is no nitrogen tank, no delivery schedule and no per-session gas cost. The trade is power and mass: it needs a three-phase supply, weighs 500-650 kg against the nitrogen cabins' 450, and reaches about -80C as the Simple build or -110C as the Grand.
USA & Europe (Ukraine, Poland)
Made in
Cryotherapy
Space planning
Reference the modality footprint before choosing a unit
This product page does not have an exact 3D model yet. The planning references below are generic envelopes tied to the listed modality, not this manufacturer's product.
Explore this generic equipment footprint, then place it in your studio plan.
Generic reference model
Cryo chamber
4.5′ × 5.5′ floor envelope
Generic planning geometry for early space planning. It is not a manufacturer-specific product, installation drawing, or purchasing specification; confirm the selected model's final envelope, service clearances, utilities, and ceiling requirements before ordering.
Place reference in planner
Key features
- Fully electric refrigeration — no liquid nitrogen storage, deliveries or per-session gas consumption
- Refrigeration integrated into the chamber body rather than housed in a separate cabinet beside it
- 13.6-15.6 inch Android touchscreen with Wi-Fi, remote monitoring and mobile app control
- Session scheduling and operating-time management from the touchscreen or companion app
- Selectable heat rejection — air cooling, water cooling, or a dedicated external chiller
- Premium water-resistant interior materials, integrated LED illumination and a glass and mirror exterior door
- Consecutive sessions once at operating temperature, with no tank depleting per client
- Extended temperature display for clear visual monitoring
Specifications
- Temperature (Simple)
- Designed to achieve approximately -80C (-112F), depending on configuration and operating conditions
- Temperature (Grand)
- Designed to reach approximately -110C (-166F), depending on configuration and operating conditions
- Dimensions
- 223 x 132 x 240 cm (88 x 52 x 94.5 in); 330 cm length with door open
- Weight (Simple)
- 500 kg
- Weight (Grand)
- 650 kg
- Power (Simple)
- 3.5 kWh average, 7.5 kW max, up to 25A per phase
- Power (Grand)
- 7 kWh average, 12 kW max, up to 30A per phase
- Voltage
- 3-phase, 400V/50Hz or 208V/60Hz
- Cooling method
- Integrated electric refrigeration — no routine liquid nitrogen
- Refrigeration
- Single compressor (Simple); dual compressor (Grand)
- Heat rejection options
- Air cooling, water cooling, or external chiller configuration
- Control panel
- 13.6-15.6 inch Android touchscreen with Wi-Fi and mobile app control
