Vacuactivus · Cryotherapy chambers
Vacuactivus Antarctica Electric
The plug-and-play build in Vacuactivus's electric line: preset modes run the session end to end, and the maker lists connection options ranging from a standard single-phase wall outlet up to three-phase. Cooling is a sealed compressor loop, so nothing is stored, delivered or vented.
USA & Europe (Ukraine, Poland)
Made in
Cryotherapy
Space planning
Reference the modality footprint before choosing a unit
This product page does not have an exact 3D model yet. The planning references below are generic envelopes tied to the listed modality, not this manufacturer's product.
Explore this generic equipment footprint, then place it in your studio plan.
Generic reference model
Cryo chamber
4.5′ × 5.5′ floor envelope
Generic planning geometry for early space planning. It is not a manufacturer-specific product, installation drawing, or purchasing specification; confirm the selected model's final envelope, service clearances, utilities, and ceiling requirements before ordering.
Place reference in planner
Key features
- Electric cooling, no liquid nitrogen required
- Fully automated sessions via 10.1 inch touchscreen
- Turbo mode for enhanced temperature sensation
- Double-layer thermal glass insulation
- Water cooling or air cooling options
Specifications
- Temperature rating
- Up to -100°C (-148°F), version-dependent
- Cooling system
- Heat exchanger, compressor, liquid separator and evaporator — electric, no liquid nitrogen
- Cooling variants
- Air-cooled, water-cooled or chiller, chosen at order
- Glazing
- Double-layer thermal glass, exterior safe to touch
- Control panel
- 10.1-inch commercial touchscreen running preset, fully automated session modes
- Dimensions (Simple)
- 1870 x 1105 x 2292 mm
- Dimensions (Grand)
- 2230 mm length
- Power (Simple)
- 3-phase 400V/50Hz or 208V/60Hz, up to 25A/phase, 8.5 kWh
- Power (Grand)
- Up to 30A/phase, 12.5 kWh
- Electrical connection options
- Vacuactivus lists versions from a standard single-phase 220 V or 110 V outlet up to three-phase — confirm which applies to the build quoted
- Pre-cooling time
- Up to 60 minutes
- Water-cooled plumbing
- 3/4-inch PVC water line and 2-inch drain
