Vacuactivus Antarctica WBC Electric
The walk-in build in Vacuactivus's electric line: the client's head sits inside the cooled zone rather than above it, which is the manufacturer's stated reason for the design — it argues neck and head carry most of the body's cold receptors. Rated to -80°C as the Simple build, -110°C as the Grand.
USA & Europe (Ukraine, Poland)
Made in
Cryotherapy
Space planning
Reference the modality footprint before choosing a unit
This product page does not have an exact 3D model yet. The planning references below are generic envelopes tied to the listed modality, not this manufacturer's product.
Explore this generic equipment footprint, then place it in your studio plan.
Generic reference model
Cryo chamber
4.5′ × 5.5′ floor envelope
Generic planning geometry for early space planning. It is not a manufacturer-specific product, installation drawing, or purchasing specification; confirm the selected model's final envelope, service clearances, utilities, and ceiling requirements before ordering.
Place reference in planner
Key features
- Breathable pre-cooled air circulation, no nitrogen vapor exposure
- 10.1 inch touchscreen control panel
- Built-in sound system with microphone
- Auto-dry system with warm air circulation
- Frosted glass door with step access
Specifications
- Temperature rating (Simple)
- -80°C (-112°F)
- Temperature rating (Grand)
- -110°C (-166°F)
- Session duration
- 1-3 minutes
- Cabin design
- Walk-in whole-body — head inside the cooled zone, entered through a frosted glass door with a step
- Cooling system
- Closed-loop mechanical refrigeration: compressor, condenser, expansion valve and evaporator; no nitrogen consumed per session
- Air supply
- Pre-cooled breathable air circulated by fan; no cryogenic gas contacts skin or airway
- Dimensions
- 1870 mm (73 in) Simple / 2230 mm (86 in) Grand length, 1105 mm (43 in) width, 2292 mm (92 in) height
- Power
- 3-phase 400V/50Hz or 208V/60Hz; Simple up to 25A/phase, 8.5 kWh; Grand up to 30A/phase, 12.5 kWh
- Pre-cooling time
- Up to 60 minutes
- Control panel
- 10.1-inch touchscreen, plus a WiFi path for remote start/stop and parameter adjustment
- Room requirement (air-cooled)
- From 15 m², ≥5000 m³/h fresh-air intake, room held at ≤20°C and 30% humidity, rubber waterproof flooring
- Room requirement (water-cooled)
- From 12 m², 3/4-inch PVC water line, 2-inch drain, cold water supply up to 1.5 m³/h
